11.FINAL REDUCTION/
TRANSMISSION SYSTEM UXV 500
Install and tighten the nut to the specified
torque by using the special tool.
Torque: 11 kgf-m (110 N-m, 79.2 lb-ft)
Special tool:
Nut wrench A120E00066
Apply clean engine oil to the new oil seal lip
then install the oil seal.
Oil Seal Nut
FRONT SIDE BEARING
Remove the oil seal.
Remove the snap ring.
Oil Seal Snap Ring
Remove the bearing by using the special tool.
Special tool:
Bearing Puller A120E00037
Install the new bearing by using the special
tool.
Special tool:
Bearing driver A120E00014 Bearing Puller Bearing Driver
11-15
