16. BRAKE SYSTEM UXV 500
REAR BRAKE PADS
Rear brake
Remove the rear wheel. (refer to the
"REAR WHEEL
REMOVAL/INSPECTION/
INSTALLATION" section in the chapter
15).
The replacement of rear brake and front
brake pads are the same.
Rear brake (combined)
Remove the rear wheel. (refer to the
"REAR WHEEL
REMOVAL/INSPECTION/
INSTALLATION" section in the chapter
15).
Remove the two brake pad pins from the
brake caliper.
Remove the two mounting bolts from brake
caliper and then remove brake caliper.
Do not operate the brake lever during
or after brake pad removal.
Replace the brake pads as a set,
otherwise braking performance will be
adversely affected.
16-5
