          11. DRIVE AND DRIVEN PULLEY                                      MYROAD 700i


                                                 Washer/Bolt   Drive pulley face
 Install the drive pulley face and washers.
 Apply oil to the drive pulley face bolt
 threads.
 Hold the drive face with the special tool and
 tighten the bolt to the specified torque.

 Torque: 10~12 kgf·m

 Special tool:
      Universal holder            A120E00017


                                                               Universal holder




                                                                     11-20
