3. INSPECTION/ADJUSTMENT MYROAD 700i
Change the engine oil with the engine at
normal operating temperature and the scooter
on its center stand to assure complete and
ENGINE OIL rapid draining.
OIL LEVEL INSPECTION Remove the oil filler cap from the right
crankcase cover.
Start the engine and let it idle for 23
minutes.
Turn off the engine and support the scooter
level surface.
Check the engine oil level. The level must be
H
maintained between the upper H (1) and
lower level L (2) marks on the oil inspection
L
screen (3).
If the oil level is below or near the lower
level line, add the recommended engine oil
until the oil level is to the upper level.
Engine oil capacity: 3.0 L
Engine oil exchanging capacity: 2.6 L
Recommended engine oil:
KYMCO 4-stroke oil or equivalent motor
oil API service classification: SJ
Viscosity: SAE 5W50
Other viscosities shown in the chart may
be used when the average temperature in
your riding area is within the indicated
range.
ENGINE OIL & STARINER SCREEN
When running in very dusty conditions, oil
changes should be performed more frequently
than specified in the maintenance schedule.
Please dispose of used engine oil in a manner
that is compatible with the environment. We
suggest you take it in a sealed container to
your local recycling center or service station
for reclamation. Do not throw it in the trash
or pour it on the ground or down a drain.
Used engine oil may cause skin cancer if
repeatedly left in contact with the skin for
prolonged periods. Although this is unlikely
unless you handle used oil on a daily basis, it
is still advisable to thoroughly wash your
hands with soap and water as soon as possible
after handling used oil.
3-13
