11. DRIVE AND DRIVEN PULLEY MYROAD 700i
Install the drive belt into the driven pulley. Lock Nut Wrench
Squeeze and hold the drive belt by your hand.
Set the clutch spring compressor over the
clutch/driven pulley assembly and hold the
spring compressor in a vice.
Special tool:
Clutch Spring Compressor A120E00053
Compress the driven face spring.
Install and tighten the clutch drive plate nut
to the specified torque.
Clutch spring compressor
Torque:
7~8 kgf·m
Drive Belt
Install the drive belt and clutch/driven pulley
assembly.
Install the drive belt with the arrow mark
facing the direction.
Clutch/Driven Pulley Assembly
Hold the clutch outer with the special tool as
shown.
Clutch outer Nut
Special tool:
Universal holder A120E00017
Install the collar and nut.
Tighten the nut to the specified torque.
Torque:
8~9 kgf·m
Universal holder
11-19
