17. BRAKE SYSTEM MYROAD 700i
Brake Hose
FRONT BRAKE CALIPER
REMOVAL
Drain the front brake hydraulic system or
combination brake hydraulic system.
Remove the brake pads.
Remove the oil bolts, sealing washers and
brake hose from the brake caliper.
Bolts Sealing Washers
Bolts
Remove the mount bolts and front brake
caliper.
Brake Caliper
DISASSEMBLY
Remove pad spring from the caliper body.
Do not remove the retainer from the
bracket unless replacement.
Pad Spring Retainer
17-20
