          16. REAR FORK/REAR WHEEL/
    REAR SHOCK ABSORBER                                               MYROAD 700i


 DISASSEMBLY                                     Brake Disc

 Wheel
 Remove the brake disc bolts and rear brake
 disc.




                                                              Outer Side Collar

 REAR FORK BEARING
 REPLACEMENT

 Remove the outer side collar from the rear
 fork.




 Remove the dust seal from the rear fork.




                                              Dust Seal

                                                                           16-6
