17. BRAKE SYSTEM MYROAD 700i
"UP" Mark Master Cylinder
Install the rear master cylinders and holders
with the "UP" mark facing up.
Install the bolts and tighten the upper bolt
first then tighten the lower bolt to the
specified torque.
Torque: 1.2 kgf·m
Bolt
Sealing Washers
Rest the brake hose eyelet against the stopper.
Install the brake hose eyelet with the oil bolt
and new sealing washers.
Tighten the oil bolt to the specified torque.
Torque: 3.5 kgf·m
Brake Hose Bolt
Connect the brake light switch connectors.
Fill the reservoir to the upper level and bleed
the brake system.
Brake Light Switch Connectors
17-19
