          3. INSPECTION/ADJUSTMENT                          MYROAD 700i

 REAR SUSPENSION INSPECTION

 Check the action of the shock absorber by
 compressing it several times.
 Check the entire shock absorber assembly for
 signs of leaks, damage or loose fasteners.
 Replace damaged components which cannot
 be repaired.
 Tighten all nuts and bolts.




 NUTS, BOLTS, FASTENERS

 Check that all chassis nuts and bolts are
 tightened to their correct torque values (page
 1-9).
 Check that all safety clips, hose clamps and
 cable stays are in place and properly secured.


 WHEELES/TIRES

 Tire pressure should be checked when the
 tires are cold.




                                                    3-24
