4. LUBRICATION SYSTEM MYROAD 700i
Dowel Pin
ASSEMBLY
Dip all parts in clean engine oil.
Install the outer rotor into the oil pump body.
Install the inner rotor into the outer rotor.
Install the oil pump shaft.
Install the pin onto the oil pump body.
Install the oil pump cover onto the oil pump
body by aligning the dowel pin.
Oil Pump Cover
Oil Pump Cover Oil Pump Cover
Install and tighten the bolts to the specified
torque.
Torqur: 1.2 kgf·m
Bolts Screw
Oil Pump
INSTALLATION
Install the oil pump and tighten the two bolts
securely.
Make sure the pump shaft rotates freely
and arrow on the oil pump is upside.
Bolts
4-7
