10. CYLINDER/PISTON MYROAD 700i
Piston/Piston pin
Measure the piston O.D. at the point (A) from 10 mm
the bottom and 90° to the piston pin hole.
(A)
Service Limit :
76.825 mm at (A): 10 mm
Measure the piston pin hole. Take the
maximum reading to determine the I.D..
Service Limit:
18.018 mm
Measure the piston pin O.D. at piston and
connecting rod sliding areas.
Service Limit:
17.894 mm
Measure the piston-to-piston pin clearance.
Service Limit: 0.044 mm
10-6
