10. FINAL REDUCTION PEOPLE 125/150
BEARING REPLACEMENT (LEFT
CRANKCASE)
Remove the drive shaft.
Remove the drive shaft oil seal.
Remove the left crankcase bearings using a
bearing remover.
Pilot
Drive new bearings into the left crankcase.
Install a new drive shaft oil seal.
FINAL REDUCTION ASSEMBLY
Install the drive shaft into the left crankcase.
Inspect the drive shaft and gear for wear or
damage.
Drive Shaft
Final Gear
Install the final gear and final shaft into the
left crankcase.
Install the countershaft and gear into the left
crankcase.
Install the washer onto the countershaft.
Install the dowel pins and a new gasket.
Countershaft Drive Shaft
Bearing Remover, 17mm Install the transmission case cover.
10-5
