11. CRANKCASE/CRANKSHAFT PEOPLE 125/150
CRANKCASE SEPARATION
Remove the two crankcase attaching bolts.
Separate the left and right crankcase halves.
Do not damage the crankcase gasket
surface.
Crankcase Bolts
Gasket
Remove the gasket and dowel pins.
Dowel Pins
Remove the crankshaft from the left
crankcase.
Clean off all gasket material from the
crankcase mating surfaces.
Avoid damaging the crankcase mating
surfaces.
11-3
