          3. INSPECTION/ADJUSTMENT                      UXV 500


 CLEAN AIR FILTER ELEMENT

 Wash the element gently, but throughly in
 solvent.
 Use parts cleaning solvent only. Never
   use gasoline or low flash point solvents
   which may lead to a

 Squeeze the excess solvent out of the
 element and let dry.
 Do not twist or wring out the foam
   element. This could damage the foam
   material.

 Apply the engine oil.
 Squeeze out the excess oil.
 The element should be wet but not
   dripping.

 More frequent replacement is required when
 riding in unusually dusty or rainy areas.




                                                3-6
