          2. FRAME COVERS/EXHAUST MUFFLER              UXV 500


 ENGINE GUARD

 REMOVAL/INSTALLATION

 Remove the 6 bolts from the engine guard,
 then remove the engine guard,.

 Installation is in the reverse order of
 removal.




  GUARD BOOT

 REMOVAL/INSTALLATION

 Remove the 2 bolts from the guard boot,
 then remove the guard boot,.

 Installation is in the reverse order of
 removal.




 GUARD R/L BOOT

 REMOVAL/INSTALLATION

 Remove the 1 bolts from the guard boot,
 then remove the guard boot,.

 Installation is in the reverse order of
 removal.




2-5
