          2. INSPECTION/ADJUSTMENT                                                        ZING125

 SERVICE INFORMATION
 GENERAL

   WARNING
 ·Before running the engine, make sure that the working area is well-ventilated. Never run the
  engine in a closed area. The exhaust contains poisonous carbon monoxide gas, which may
  cause death to people.
 ·Gasoline is extremely flammable and is explosive under some conditions. The working area
  must be well-ventilated and do not smoke or allow flames or sparks near the working area or
  fuel storage area.



 SPECIFICATIONS

 ENGINE                                               CHASSIS
 Throttle grip free play : 26mm                       Front brake free play: 1020mm
 Spark plug gap             : 0.60.7mm                Rear brake free play : 1020mm
 Spark plug specification : NGK-CR8E                  Brake fluid          : DOT-4
 Valve clearance : IN: 0.06mm
                    EX: 0.06mm
 Cylinder compression : 142 kg/cm
 Ignition timing            : 24°/4000rpm
 Idle speed                 : 1600100rpm
 Engine oil capacity:
    At disassembly : 1.1 liter
    At change        : 0.9 liter


 TIRE PRESSURE

                                      1 Rider                   2 Riders
           Front                    1.75kg/cm                 1.75kg/cm
            Rear                    2.0kg/cm                  2.25kg/cm

 TIRE SIZE:
   Front : 3.00­18 47P
   Rear : 130/90­15 66P


 TORQUE VALUES
  Front axle nut 5.57.0 kg-m
  Rear axle nut  6.08.0 kg-m




2-1
