4. FUEL SYSTEM K-PIPE 125
CARBURETOR REMOVAL
Remove the skirt R/L side. (page 14-3)
Remove the center cover. (page 14-4).
Remove the leg shield.
Loosen the air cleaner connecting tube band.
Remove the carburetor top (page 4-6).
Throttle Valve
Choke Cable
Remove the fuel tube from the carburetor.
Remove the choke cable.
Remove the carburetor mounting bolts.
Remove the insulator, O-ring and carburetor.
Fuel Tube
CARBURETOR DISASSEMBLY
Loosen the drain screw to drain the
gasoline from the float chamber.
· Keep sparks and flames away from the
work area.
· Drain gasoline into a clean container.
Drain Screw
4-7
