          4. LUBRICATION SYSTEM                                                         STRYKER 125/150



  ENGINE OIL/OIL FILTER
                                                      Upper Limit
  OIL LEVEL
 · Place the motorcycle upright on level
      ground for engine oil level check.
    · Run the engine for 23 minutes and
      check the oil level after the engine is
      stopped for 23 minutes.
  If the level is near the lower limit, fill to the
  upper limit with the specified engine oil.



                                                      Lower Limit

  OIL CHANGE
 The engine oil will drain more easily
    while the engine is warm.
  Remove the two engine below protecting
  cover bolts and the below protecting cover.
  Remove the drain bolt to drain the engine
  oil thoroughly.
  Check the drain bolt washer for damage or
  deformation and replace with a new one if
  necessary.


                                                      Drain Bolt


  Remove the oil filter screen cap and then
  remove the oil filter screen and spring.
  Clean the oil filter screen with compressed
  air.
  Check the filter screen cap O-ring for damage
  or deformation and replace if necessary.
  Install the oil filter screen, spring and filter
  screen cap.
  Torque: 1.02.0kg-m
 Do not install the oil filter screen upside
    down.
  Oil Capacity: At disassembly : 1.0 liter
                  At change        : 0.9 liter        Oil Filter Screen Cap
  Check for oil leaks and then start the engine
  and let it idle for few minutes.
  Stop the engine and recheck the oil level.

                                                                                       4-2
