10. DRIVE PULLEY/DRIVEN PULLEY/CLUTCH UXV 500
Place a block on the plate nut. Block
Compress the spring by using a
commercially available puller, install the
drive belt.
The drive belt should be installed so
that the arrows on the drive belt
periphery point in the normal turning
direction.
The drive belt contact surface of the
driven face should be thoroughly
cleaned.
Install the driven pulley assembly and drive Nut
V-belt.
Use the special tool to hold driven pulley,
then tighten the nut to the specified torque.
Torque: 10 kgf-m (100 N-m, 72 lbf-ft)
Apply oil to the threads
Special tools:
Y-type holder A120E00056
Y-type Holder
Apply lubricant
Apply lubricant to the drive face boss inner
surface, then install the drive pulley.
Drive Face Boss
10-7
