18. MOVIE CARBURETOR EURO 3
MOVIE SYSTEM
DISASSEMBLY
Loosen the drain screw to drain the gasoline
from the float chamber.
· Keep sparks and flames away from the
work area.
· Drain gasoline into a clean container.
· Do not loosen or tighten the painted
bolts and screws of the carburetor.
Loosening or tightening them can
cause throttle and piston valve
synchronization failure.
Bend the guide straight, then remove the
auto choke wire.
Guide
Top Cap
Remove the two screws and top cap.
18-6
