          2. FRAME COVERS/EXHAUST MUFFLER                                                 MXU 300/250


 SERVICE INFORMATION

 GENERAL INSTRUCTIONS
 · When removing frame covers, use special care not to pull them by force because the cover joint
   claws may be damaged.
 · Make sure to route cables and harnesses according to the Cable & Harness Routing.


 TORQUE VALUES
 Exhaust muffler lock bolt       3.5 kgf-m (35 Nm, 25 lbf-ft)
 Exhaust muffler lock nut        3.5 kgf-m (35 Nm, 25 lbf-ft)


 TROUBLESHOOTING
 Noisy exhaust muffler
 · Damaged exhaust muffler
 · Exhaust muffler joint air leaks
 Lack of power
 · Caved exhaust muffler
 · Exhaust muffler air leaks
 · Clogged exhaust muffler




                                                                                             2-2
