3. INSPECTION/ADJUSTMENT MXU 300/250
CLEAN AIR FILTER ELEMENT
Wash the element gently, but throughly in
solvent.
Use parts cleaning solvent only. Never
use gasoline or low flash point solvents
which may lead to a fire or explosion.
Squeeze the excess solvent out of the
element and let dry.
Do not twist or wring out the foam
element. This could damage the foam
material.
Apply the engine oil.
Squeeze out the excess oil.
The element should be wet but not
dripping.
More frequent replacement is required when
riding in unusually dusty or rainy areas.
Air Cleaner Housing
AIR CLEANER HOUSING DRAIN
Remove the drain tube (under air cleaner
case) by removing the clip.
Drain the deposits.
Reinstall the drain tube, securing it with the
clip.
Drain Tube Clip
AIR FILTER FOR DRIVE BELT
To clean the air filter:
Remove front center cover. (See page 2-7)
Remove air filter.
Tap the element lightly to remove most of
the dust and dirt.
Blow out the remaining dirt with
compressed air.
Installation is in the reverse order of
removal.
Air Filter
If necessary replace the air filter.
3-6
