          8.ENGINE REMOVAL/                                                              MYROAD 700i
  INSTALLATION

 Remove the A.C.G. connector.                                     A.C.G. connector




 Disconnect the engine ground cable.             Engine ground cable




                                                   bolt


                                                 Cooler's tubes           water pipe
 Disconnect the cooler's tubes and water pipe.




                                                                                       8-4
