3. INSPECTION/ADJUSTMENT MYROAD 700i
RADIATOR COOLANT
Place the scooter on its center stand.
The reserve tank is under left footboard.
Check the coolant level through the
inspection window (1) at the
(1)
left side skirt while the engine is at the (2)
normal operating
temperature with the scooter in an upright F (3)
position. If the coolant
level is below the LOWER level mark (3),
remove the left floor L
mat, remove the lid screw and reserve tank
lid and the
Reserve tank cap (4) and add coolant mixture
until it reaches the upper
level mark (2). (4)
Remove the left floor mat and remove screw
and reserve tank lid.
Remove reserve tank cap.
Check to see if there are any coolant leaks
when the coolant level decrease very rapidly.
If reserve tank becomes completely empty, Lid Screw
there is a possibility of air getting into the
cooling system.
Be sure to remove all air from the cooling
system.
Rubber plate
Reinstall the filler cap.
3-16
