4. LUBRICATION SYSTEM MYROAD 700i
OIL PRESSURE SWITCH
CHECK
Start the engine.
Check the oil pressure indicator goes out after
one or two seconds. If the oil pressure
indicator stay on, stop the engine
immediately and determine the cause.
Dust Cover
Oil Pump
OIL PRESSURE RELIEF VALVE /
OIL PUMP
REMOVAL
Remove the right crankcase cover.
Remove the pressure relief valve and O-ring
from the right crankcase
.
O-ring Oil Pressure Relief Valve
Piston Oil Pressure Relief Valve
INSPECTION
Check the operation of the pressure relief
valve by pushing on the piston.
INSTALLATION
Apply oil to a new O-ring and install the
pressure relief valve groove, and install the
relief valve to the right crankcase. O-Ring
4-4
