15. STEERING HANDLEBAR/FRONT WHEEL/
FRONT SHOCK ABSORBER MYROAD 700i
SERVICE INFORMATION
GENERAL INSTRUCTIONS
· A contaminated brake disc or pad reduces stopping power. Discard contaminated parts and clean
a contaminated disc with a high quality brake degreasing agent.
· This section covers of the front wheel , fork, handlebar, and steering.
· A jack or other support is required to support the vehicle.
· Do not twist or bend the brake hose and pipe when servicing.
· Use genuine KYMCO replacement bolts and nuts for all suspension pivots and mounting points
· Refer to section 17 for brake system information.
SPECIFICATIONS
Unit: mm
ITEM STANDARD SERVICE LIMIT
Minimum tire tread depth 1.5
Cold tire pressure Driver only Front: 2, Rear: 2.5 kgf/ cm2
Driver and passenger Front: 2, Rear: 2.5 kgf/ cm2
Axle runout 0.2
Wheel rim runout Radial 2
Axial 2
TORQUE VALUES
Handlebar bolt 2.7 kgf·m
Steering stem nut 7.0 kgf·m
Steering stem lock nut 5.5 kgf·m
Steering top thread 2.7 kgf·m
Front axle bolt 3.3 kgf·m
Front brake disc bolt 4.3 kgf·m
Lock bolt: replace with a new one.
Front fork bolt 2.3 kgf·m
SPECIAL TOOLS
Oil seal & bearing install driver A120E00014
Lock nut socket wrench A120E00023
Bearing remover A120E00037
Long socket wrench A120F00007
15-2
