          16. IGNITION SYSTEM                                         STRYKER 125/150
Blue/Yellow



 EXCITER COIL
 INSPECTION
 Disconnect the exciter coil wire coupler and
 measure the resistance between the
 black/red wire terminal and ground.
 Resistance: 272408




                                                Black/Red




16-7
