          13. A.C. G/STARTER CLUTCH                                         MYROAD 700i

                                            Reduction Gear
 Remove the reduction gear.




                                                  Nut
 Remove the nut of drive gear assembly by
 using the special tool.

 Tightened Torque: 14 kgf·m




 Special tool:
                                                   Special tool

 Nut wrench         A120E00084




13-5
