          14. CRANKCASE/CRANKSHAFT                                     MYROAD 700i

   Tighten the ten bolts in a crisscross pattern in
   several steps.                                     Left Crank Case Cover




                                                           Bolts





    Always replace the crankcases in pairs
    to ensure the coaxial function. The code
    should be the same. The set includes
    bolts as well, the part number is
    1110A-KKE5-E00.




                                                           Crank case code




14-15
