16. INSTRUMENT/SWITCHES/LIGHTS SUPER 9 50
STARTER SWITCH INSPECTION
Check for continuity between wire terminals.
Push the starter button when measuring.
Color Yellow/Red Green
Symbol ST E
FREE
PUSH
Starter Switch G Y/R
HORN SWITCH INSPECTION
Check for continuity between wire terminals.
Push the horn button when measuring.
Color Light Green Black
Symbol HO BAT2
FREE
B
PUSH
Horn Switch Lg
STOP SWITCH INSPECTION
Remove the handlebar lower cover. ( 2-7)
Disconnect the front and rear stop switch
wire couplers.
Check for continuity between the wire
terminals when the front/rear brake lever is
applied.
16-6
