          6. CYLINDER HEAD/CYLINDER/PISTON                                          SUPER 9          50

                                                                          Spark Plug Cap
 CYLINDER HEAD
 REMOVALSF10DA
 Remove the rear carrier.
 Remove the frame body cover. ( 2-2)




                                                        Fan Cover/Engine Hood
 Remove the spark plug cap.
 Remove the three bolts attaching the fan
 cover to remove the fan cover.
 Remove the two joint lock nuts on the front
 of the exhaust muffler and then remove the
 two exhaust muffler lock bolts.
 Remove the bolt attaching the engine hood
 to remove the engine hood.
 The installation sequence is the reverse of
 removal.

   When installing the exhaust muffler,
   first tighten the two nuts on the front
   and then tighten the two bolts.
                                                                  Bolts
                                                               Cylinder head Bolts
 Remove the spark plug.
 Remove the cylinder head bolts and the
 cylinder head.

   Loosen the bolts diagonally in 2 or 3
   times.

 Remove the cylinder head gasket.




                                               Cylinder Head               Spark Plug



6-3
