5. Place the float assembly (with float valve) into posi-
tion and secure to the carburetor with the float pin.
CC761A
3. Install the starter jet and slow jet. Tighten securely.
KC0024
NOTE: Check float height by placing the carbure-
tor on its side w/float contacting the needle; then
measure with a caliper the height when the float
arm is in contact with the needle valve. Float arm
height should be 17 mm.
KC0032A
4. Install the main jet into the needle jet holder and
tighten securely; then install the needle jet and
needle jet holder assembly into the carburetor and
tighten securely.
KC0035
6. Place the float chamber into position making sure
the O-ring is properly positioned; then secure with
the Phillips-head screws.
KC0031
KC0063A
KC0030A
4-6
