          3. LUBRICATION SYSTEM                                                           K-PIPE 50
                                                                         Upper Limit
 ENGINE OIL/OIL FILTER
 OIL LEVEL
 Place the motorcycle upright on level
    ground for engine oil level check.
    Run the engine for 23 minutes and
    check the oil level after the engine is
    stopped for 23 minutes.
 Check the oil level. If the level is near the
 lower limit, fill to the upper limit with the                           Lower Limit
 specified engine oil.



 OIL CHANGE
 The engine oil will drain more easily
   while the engine is warm.
 Remove the drain bolt to drain the engine oil
 thoroughly.
 Check the drain bolt washer for damage or
 deformation and replace with a new one if
 necessary.
                                                           Drain Bolt



 ENGINE OIL FILTER
 Remove the right crankcase cover attaching
 bolts and right crankcase cover.
 Remove the dowel pins and gasket.
 Clean oil filter screen.



                                                              Bolts

 Specified Oil: SAE15W40
 API service classification: SG
 Oil Capacity: At disassembly : 1.0 liter
                  At change       : 0.9 liter
 Check for oil leaks and then start the engine
 and let it idle for few minutes.
 Stop the engine and recheck the oil level.




                                                 Oil Filter Screen Cap

3-3
