4. FUEL SYSTEM K-PIPE 50
CARBURETOR REMOVAL
Remove the front cover (page 14-3).
Loosen the air cleaner connecting tube band.
Carburetor top
Remove the carburetor top (page 4-6).
Choke Cable
Remove the fuel tube from the carburetor.
Remove the choke cable.
Remove the carburetor mounting bolts.
Remove the insulator, O-ring and carburetor.
Bolts Fuel Tube
CARBURETOR DISASSEMBLY
Loosen the drain screw to drain the gasoline from
the float chamber.
Keep sparks and flames away from the work
area.
Drain gasoline into a clean container.
Drain Screw
4-7
