          11. FRONT WHEEL/SUSPENSION/
    STEERING                                                           QUANNON 125

 ASSEMBLY                                          Bearing Driver Handle
 Pack all bearing cavities with grease. First
 drive in the right bearing and then install the
 distance collar. Finally, drive in the left
 bearing.




 Install the brake disk and tighten the five
 nuts.
 Apply grease to the dust seal and install the
 dust seal.




                                                           Dust Seal          Brake Disk
                                                           Grooves         Flange Tab
 Install the speedometer gearbox by aligning
 the tabs with the grooves.




                                                   Speedometer Gearbox     Dust Seal

 Apply grease to the speedometer gearbox
 and dust seal, then install them to the wheel
 from the left side.




11-9
