15. IGNITION SYSTEM K-PIPE 50
IGNITION COIL
CONTINUITY TEST
This test is to inspect the continuity of
ignition coil.
Remove the right decorative cover.
Measure the resistance between the ignition
coil primary coil terminals.
Resistance(20): 0.10.3
Ignition Coil
Measure the secondary coil resistance
between the spark plrg cap and the primary
coil terminal as Figure A shown.
Resistance(20)(with plug cap): 10
15K
Figure A
Measure the secondary coil resistance
between the ignition coil terminal and the
primary coil terminal as Figure B shown.
Resistance(20) (without plug cap): 4.2
5.2K
Figure B
15-4
