17. STARTING SYSTEM K-PIPE 50
Continuity
Check for continuity from the cable terminal
to the brush holder and from the cable
terminal to the brush.
Cable terminal and brush holder
No continuity: normal
Cable terminal and brush
Continuity: normal
No Continuity
Inspect the brushes for wear or damage.
Measure the brush length.
Service limit: 8.5mm
Inspect the brush springs for wear or fatigue.
Brush Springs
INSDTALLATION
Install a new O-ring and apply oil to it.
Install the starter motor and tighten the three
mounting bolts securely.
Install the ground terminal properly as
f shown with starter motor mounting bolt.
f
fConnect the starter motor connector.
Install the starter clutch (page ?)
Install the front cover.
17-4
