          2. INSPECTION/ADJUSTMENT                                                              QUANNON 125

 MAINTENANCE SCHEDULE
 Perform the periodic maintenance at each scheduled maintenance period.
 I: Inspect, and Clean, Adjust, Lubricate, Refill, Repair or Replace if necessary.
 A: Adjust     C: Clean R: Replace T : Tighten

                        Whichever                         Regular Service Mileage (km)
              Frequency comes
                        first
  Item
                                        1000     2000 3000 4000 5000 6000 7000 8000 9000 10000 11000 12000
                                          R
 Engine oil                            300km      R         R         R         R          R          R

 Engine oil filter screen                         C         C         C         C          C          C

 Fuel filter screen                                                   R                               R

 Valve clearance                                            A                   A                     A

 Carburetor                                                  I                   I                     I

 Air Cleaner                Note 2,3     C        C         C         R         C          C          R

 Spark plug                                  Clean at every 6000km and replace if necessary

 Brake system                            A        A         A         A         A          A          A

 Drive chain                                      A         A         A         A          A          A

 Suspension                              I                                       I

 Nuts, bolts, fasteners                  T        T         T         T         T          T          T

 Tire                                    I        I          I         I         I         I           I

 · In the interest of safety, we recommend these items should be serviced only by an authorized
   KYMCO motorcycle dealer.
   Note: 1. For higher odometer readings, repeat at the frequency interval established here.
          2. Service more frequently when riding in dusty or rainy areas.
          3. Service more frequently when riding for long distance, in rain or at full throttle.




                                                                                                  2-2
