6. CYLINDER HEAD/VALVES STRYKER 125/150
CAMSHAFT HOLDER DISASSEMBLY Rocker Arm Shafts
Remove the stopper bolt and the stopper.
Take out the valve rocker arm shafts using
a 5mm bolt.
Stopper Rocker Arms
CAMSHAFT HOLDER INSPECTION
Camshaft Holder
Inspect the camshaft holder, valve rocker
arms and rocker arm shafts for wear or
damage.
If the valve rocker arm contact surface is
worn, check each cam lobe for wear or
damage.
Rocker Arm Shafts
Measure the I.D. of each valve rocker arm.
Service Limits: IN: 12.10mm replace if
over
EX:12.10mm replace if over
Measure each rocker arm shaft O.D.
Service Limits: IN: 11.91mm replace if over
EX:11.91mm replace if over
6-7
