17. CHARGING SYSTEM STRYKER 125/150
PERFORMANCE TEST
Perform this test with a fully charged battery.
Start and warm up the engine for 10 minutes.
Connect the battery positive cable to the
ammeter positive probe and then connect the
ammeter negative probe to the battery
positive terminal.
Then, connect the voltmeter across the
battery terminals to test the charging voltage.
CHARGING PERFORMANCE:
Headlight Charging 4000rpm 10000rpm
Switch rpm
OFF (Day) 1400 rpm 5.5A 9A
max.
ON (Night) 2700 rpm 1.7A 5A
max.
LIMIT VOLTAGE TEST:
Start the engine and gradually increase the Negative Cable
engine speed to measure the limit voltage.
Limit Voltage: 12.80.5V
Note: Test when the battery is fully charged.
When testing the limit voltage, use a
tachometer for operation.
Positive Cable
17-5
