11. FUEL SYSTEM STRYKER 125/150
Connecting Tube Band Throttle Cable
CARBURETOR INSTALLATION
Tighten the drain screw.
Install the carburetor onto the intake
manifold, aligning the tab on the carburetor
with the cutout in the intake manifold.
Tighten the intake manifold band screw.
Install the air cleaner connecting tube and
tighten the band screw.
Connect the throttle cable to the throttle
wheel on the carburetor.
Tighten the lock nut.
Carburetor Intake Manifold
Vacuum Tube
Connect the fuel tube and vacuum tube to
the carburetor.
Fuel Tube
Connect the auto bystarter wire connector.
Perform the following inspections and
adjustments:
-Throttle grip free play
-Carburetor idle speed
Auto Bystarter Wire
11-13
